Turbine Flow Meters with BSPP Threads for lubricating and non-lubricating media
HM R
The HM R turbine flow meter series (R for Female Inch Threads) is used to measure continuous and discontinuous flow rates. They are mainly used for lubrication and non-lubrication media. They are particularly suitable for low and medium viscosity liquids, such as water, emulsions, glycol mixtures and light oils. Even the measurement of cryogenic fluids is possible.
| Measuring Ranges | 0.3 up to 400 l/min |
|---|---|
| Repeatability | ±0.05 % (under the same conditions) |
| Linearity | ±1 % of actual flow |
| Viscosity Range | 0.8 up to 30 mm²/s |
| Materials | Housing: as per DIN 1.4404 [AISI 316L] (others on request) |
| Pressure | up to 630 bar [9,140 psi] |
| Medium Temperature | -60 °C up to +350 °C [-70 °F up to +662 °F] |
