For lubricating and non-lubricating liquids

Measuring Ranges

0.005 up to 150 l/min

Measuring Accuracy

up to ±0.1 %

Repeatability

±0.05 % (under the same conditions)

Linearity

±0.5 % of actual flow (viscosity ≥ 30 mm²/s)

Materials

Housing: as per DIN 1.4305 [AISI 303], 1.4404 [AISI 316L]
Gears: as per DIN 1.4122, 1.4501 [AISI F55]
Bearing: Tungsten carbide sleeve bearing
Seals: FKM, PTFE (others on request)

Pressure

up to 420 bar [6,000 psi]

Medium Temperature

-40 °C up to +180 °C [-40 °F up to +356 °F] (others on request)
